Doppler

Dead-simple, ultra-fast digital signal processing.

Doppler is a C99 DSP library covering the core building blocks: NCO, FIR filter, FFT, polyphase resampling, and ZMQ-based signal streaming. Python and Rust bindings wrap the same C core — no reimplementation, no divergence between languages, C throughput from Python.

What's inside

NCO — 32-bit phase accumulator, 2¹⁶-entry LUT, AVX-512 batch generation, FM ctrl port
FIR filter — AVX-512 complex taps, CI8/CI16/CI32/CF32 input types
FFT — 1D and 2D, selectable backend (FFTW or pocketfft)
Resampler — polyphase and DPMFS (608 B coefficient bank, L1-resident); halfband 2:1 decimator
Polyphase design tools — fit_dpmfs, optimize_dpmfs, kaiser_prototype in Python
Signal streaming — ZMQ transport (PUB/SUB, PUSH/PULL, REQ/REP); C and Python; multi-machine
Circular buffers — double-mapped ring buffers, lock-free SPSC, zero-copy IPC (F32/F64/I16)
Spectrum analyzer — doppler-specan: real-time FFT display, waterfall, web UI
Pipeline CLI — doppler compose: wire blocks into processing chains with a YAML file
Multi-language — clean C ABI; Python bindings and Rust FFI; Dopplerfile for custom blocks

Benchmarks

Measured on AMD Ryzen AI 7 350, Release build (-O3 -march=native). Re-run any suite with make blazing then the binary listed below.

NCO (`dp_nco_*`)

block=1 048 576 samples × 200 iterations — ./build/c/bench_nco_c

Rank	Variant	MSa/s	Notes
🥇	`u32`	20 341	Raw phase only — store + add, no LUT
🥈	`u32_ovf`	3 028	Raw phase + carry bit (ADD + SETB)
🥉	`cf32`	2 094	Free-running IQ — AVX-512 16-wide gather
4	`u32_ovf_ctrl`	1 424	FM ctrl + raw phase + carry
5	`u32_ctrl`	1 095	FM ctrl + raw phase
6	`cf32_ctrl`	525	FM ctrl + IQ — LUT + ctrl overhead

FIR (`dp_fir_execute_*`)

taps=19 block=409 600 samples × 100 iterations — ./build/c/bench_fir_c

Input type	MSa/s	Notes
`CI8`	317	8-bit complex integer input
`CF32`	280	32-bit complex float input
`CI16`	235	16-bit complex integer input

FFT (`dp_fft*`)

FFTW backend, estimate plan, 1 thread, complex double — ./build/c/bench_fft_c

1D (fft1d_execute / fft1d_execute_inplace)

Size	Out-of-place MSa/s	In-place MSa/s
1 024	925	757
4 096	474	379
16 384	146	139

2D (fft2d_execute / fft2d_execute_inplace)

Size	Out-of-place MSa/s	In-place MSa/s
64 × 64	722	616
128 × 128	252	241
256 × 256	33	30

Ring buffer (`dp_f32 / dp_f64`)

Lock-free SPSC, 268 M samples, batch=4096 — ./build/c/bench_buffer_c

Type	MSa/s	GB/s
`f32` (8 B/sample)	5 129	38.2
`f64` (16 B/sample)	2 401	35.8

Quick start

=== "Python"

```python
from doppler import Nco
import numpy as np

with Nco(0.25) as nco:
    iq = nco.execute_cf32(8)
    # [ 1.+0.j  0.+1.j -1.+0.j  0.-1.j ... ]
```

```python
from doppler.fft import fft
import numpy as np

x = np.random.randn(1024) + 1j * np.random.randn(1024)
spectrum = fft(x)
```

=== "C"

```c
#include <doppler.h>
#include <dp/nco.h>

dp_nco_t *nco = dp_nco_create(0.25f);
dp_cf32_t out[1024];
dp_nco_execute_cf32(nco, out, 1024);
dp_nco_destroy(nco);
```

```c
#include <doppler.h>
#include <dp/fft.h>

size_t shape[] = {1024};
dp_fft_global_setup(shape, 1, -1, 1, "estimate", NULL);
double complex in[1024], out[1024];
dp_fft1d_execute(in, out);
```

Build

make          # build (Linux/macOS; MSYS2 on Windows)
make test     # run CTest suite
make && uv sync  # with Python bindings

Licensing

The doppler source code is MIT-licensed.

If built with FFTW support (default), the resulting binary links against FFTW (GPL). Built with -DUSE_FFTW=OFF, the pocketfft backend is used instead (BSD-3-Clause), keeping the binary MIT-licensed.
